Brand Name: JMC
Model Number: US Type
Material: Alloy Steel
Size: 1/4"-1.1/4"
Surface Treatment: Painted Color
Technology: Forged
Application: For lifting industry
Packing: in carton or gunny bag, then on steel pallet
Place of Origin: Shandong, China(Mainland)
Bussines Type: Manufacturer, Trading Company
| Connecting Link A-337 | ||||||
| CHAIN SIZE | W.L.L. | DIMENSIONS (IN.) | ||||
| (MM) | (IN.) | (LBS.) | A | B | D | E |
| 7 | 1/4 | 3500 | 0.36 | 1.88 | 0.78 | 0.66 |
| 8 | 5/16 | 4500 | 0.39 | 2.13 | 0.88 | 0.69 |
| 10 | 3/8 | 7100 | 0.52 | 2.50 | 1.03 | 0.88 |
| 13 | 1/2 | 12000 | 0.64 | 3.44 | 1.44 | 1.13 |
| 16 | 5/8 | 18100 | 0.75 | 4.13 | 1.73 | 1.41 |
| 20 | 3/4 | 28300 | 0.97 | 4.94 | 2.06 | 1.63 |
| 22 | 7/8 | 34200 | 1.06 | 5.50 | 2.31 | 2.00 |
| 25 | 1 | 47700 | 1.22 | 6.00 | 2.50 | 2.25 |
| 32 | 1.1/4 | 72300 | 1.50 | 7.43 | 3.06 | 2.56 |
